Description
- 360° ROTATABLE HEADS
- REAR EXHAUST
- AIR INLET SIZE: 1/4" NPT
- SIDE TO CENTER: 0.8"
- MAXIMUM AIR CONSUMPTION: 30 CFM (14 l/s)
- SPINDLE THREAD: 3/8"-24
***Reversible & Side Exhaust Models Available on Request
MODEL NO.
CHUCK
SPEED
WEIGHT
LENGTH
SDR10A3R3
3/8"
300 RPM
3.3 LBS
12"
SDR10A3R4
1/2"
300 RPM
3.7 LBS
12"
SDR10A6R3
3/8"
600 RPM
3.3 LBS
12"
SDR10A6R4
1/2"
600 RPM
3.7 LBS
12"
SDR10A10R3
3/8"
1000 RPM
3.3 LBS
12"
SDR10A10R4
1/2"
1000 RPM
3.7 LBS
12"
SDR10A16R2
1/4"
1600 RPM
3.2 LBS
12"
SDR10A16R3
3/8"
1600 RPM
3.3 LBS
12"
SDR10A20R2
1/4"
2000 RPM
2.9 LBS
11"
SDR10A20R3
3/8"
2000 RPM
3 LBS
11"
